A Series Tankless Chillers

2-60 Tons of Cooling

The A-Series air-cooled industrial liquid chiller delivers precise temperature control when you need to cool central coolant pits, storage tanks, or quench tanks. These systems cool metalworking fluid, hydraulic fluids, and other process liquids across diverse industrial applications.

We configure each A-Series chiller with evaporators matched to your specific fluid type and contamination levels. This design flexibility enables the system to cool water-soluble oil, oils of varying viscosities, and water-based applications with equal effectiveness.

We offer filtration systems and recirculation pumps as standard options to maintain fluid quality and ensure consistent flow rates. The A-Series options shown below include water-cooled or remote condensers, blower packages, process pumps, 100-micron fluid filters, and flow switches—allowing you to configure the exact system your operation requires.

PRODUCT SUMMARY

Cooling Capabilities:

• Delivers recirculating or inline cooling
• Uses air-cooled condenser for simple installation
• Provides capacities from 27,000 BTU/hr to 800,000 BTU/hr
• Cools water, water/glycol, water-soluble, and oil-based fluids

Design Features:

• Uses R407C refrigerant
• Offers highly customizable configurations
• Features powder-coated cabinet for durability
• Operates indoors only

Performance Specifications:

• Maintains fluid setpoint from 50º-90ºF
• Operates in ambient temperatures from 50-95ºF
• Controls temperature within ± 3ºF (Optional ± 1ºF)
• Meets UL 1995 standards (Optional cUL Certification available)

Support & Reliability:

• Includes 18-month parts and labor warranty
• Provides next-day parts availability
• Offers multiple voltage options

BASE CONFIGURATION: Brazed Plate, Cleanable, Shell/Tube Evaporators (vary w/ application); Hermetic Scroll Compressor; Cleanable Air Filters; Fused Disconnect; Hot Gas Regulator.

OPTIONS: Remote or Water-Cooled Condenser; Process Pump; 100 Micron Fluid Filter; Phase Monitor; Motorized Hot Gas Bypass; Remote Start/Stop, Remote PGD (up to 150’); Ambient Temperature Tracking; Service/Maintenance Packages; cUL Certification.
